Low cost 20 w audio amplifier

Description: This simple and inexpensive audio amplifier can be constructed using a couple of TO-220 monolithic Darlington transistors for the push-pull output stage. The frequency response is flat within 1 dB from 30 Hz to 200 kHz, with typical harmonic distortion below 0%. The amplifier requires only 1 Vrms for a full 20 W output into an 8-ohm load. Only one additional transistor is needed, the TO-92 low-noise high-gain 2N5961 (Q1), to provide voltage gain for driving the output Darlingtons. Its base (point B) serves as the tie point for AC and DC feedback, as well as for the signal input. The input resistance is 10 kΩ. The center voltage at point A is set by adjusting resistor R4. A bootstrap circuit enhances the collector supply voltage of Q1 (point C) to ensure sufficient drive voltage for Q2. This also maintains a constant voltage across R7, which acts as a current source and, along with diodes D1-D3, reduces low-signal crossover distortion.

The audio amplifier circuit utilizes a push-pull configuration to efficiently drive an 8-ohm load, delivering a robust 20 W output. The choice of TO-220 Darlington transistors for the output stage provides high current gain, allowing for effective amplification with minimal distortion, particularly in the specified frequency range. The inclusion of the 2N5961 transistor as the voltage gain stage is critical for achieving the desired performance metrics, as it provides the necessary drive to the output transistors while also allowing for effective feedback mechanisms.

The feedback network, established at the base of Q1, plays a significant role in stabilizing the amplifier's performance. The AC and DC feedback ensures linearity and minimizes distortion across the operating range. The input resistance of 10 kΩ is suitable for interfacing with standard audio sources, ensuring compatibility and ease of use.

The center voltage at point A, adjustable via resistor R4, allows for fine-tuning of the amplifier's operating point, optimizing performance based on specific application requirements. The bootstrap circuit connected to the collector of Q1 enhances the drive capability for Q2, ensuring that the output stage receives adequate voltage for linear operation. The constant voltage across R7, established by the bootstrap arrangement, functions as a current source, which is crucial for maintaining consistent output characteristics.

Furthermore, the inclusion of diodes D1-D3 within the circuit is essential for mitigating crossover distortion, particularly at low signal levels. These diodes work in conjunction with R7 to create a more linear response during the transition between the output stage's active and inactive states, promoting overall sound quality and fidelity.

This audio amplifier design exemplifies a balance of simplicity, cost-effectiveness, and performance, making it an excellent choice for various audio applications where high-quality amplification is required.This simple inexpensive audio amplifier can be constructed using a couple of T0-220 monolithic Darlington transistors for the push-pull output stage. Frequency response is fiat within 1 dB from 30 Hz to 200 kHz with typical harmonic distortion below 0%.

The amplifier requires only 1 Vrms for a full 20 W output into an 8 ohm load. Only one other transistor is needed, the TO-92 low-noise high-gain 2N5961 (Ql), to provide voltage gain for driving the output Darlingtons. Its base (point B) is the tie point for ac and dc feedback as well as for the signal input. Input resistance is 10 K The center voltage at point A is set by adjusting resistor R4. A bootstrap circuit boosts the collector supply voltage of Ql (point C) to ensure sufficient drive voltage for Q2. This also provides constant voltage across R7, which therefore acts as a current source and, together with diodes D1-D3, reduces low-signal crossover distortion.
