darkroom timer with PIC 16F84A

Description: I tried to design a timer that would do everything it needed to do but with the smallest number of pieces and simplest mode of operation. It only needs the PIC, a four digit LED display, one other IC, a resistor network, one pushbutton switch and a capacitor. It can run on batteries if you use a solid state relay to turn the exposure light on and off thereby adding a minimum of parts to make a fully functional darkroom timer. A simple regulator would add only a few extra parts and allow the use of a "wall-wart" for power. More: All the functions are in firmware, allowing the use of one switch for control. I sketched in the schematic in Eagle format and here's a jpg image, too. This text file has the parts list and some notes to help you build the timer. Here's the firmware.

The proposed timer circuit is a compact and efficient design aimed at controlling exposure time in a darkroom environment. The core of the circuit is a microcontroller, specifically a PIC (Peripheral Interface Controller), which serves as the main processing unit. The microcontroller is programmed with firmware that manages all the timer functions, enabling a single pushbutton switch to control the entire operation. This design choice minimizes the complexity of the user interface, making it user-friendly while maintaining functionality.

The timer features a four-digit LED display, which provides a clear visual indication of the countdown timer. This display is driven by the microcontroller, allowing it to show the remaining time accurately. The inclusion of a second integrated circuit (IC) could serve various purposes, such as providing additional timing functions or handling input/output operations more efficiently.

A resistor network is employed to interface the pushbutton switch and provide necessary pull-up or pull-down resistances, ensuring reliable button presses are detected by the microcontroller. The capacitor in the circuit can be used for debouncing the switch or for timing purposes, depending on the specific design implementation.

For power supply considerations, the timer circuit can operate on batteries, which is suitable for portable applications. To control the exposure light, a solid-state relay (SSR) is utilized. This component allows for the safe switching of higher voltages or currents without mechanical wear, thereby enhancing the reliability of the timer system. If a wall adapter is preferred, a simple voltage regulator can be added to the circuit, enabling the use of a "wall-wart" power supply while only introducing a minimal number of additional components.

Overall, the design emphasizes simplicity and efficiency, making it an ideal solution for darkroom timing applications. The accompanying schematic, parts list, and firmware notes further assist in the construction and implementation of the timer circuit.I tried to design a timer that would do everything it needed to do but with the smallest number of pieces and simplest mode of operation. It only needs the PIC, a four digit LED display, one other IC, a resistor network, one pushbutton switch and a capacitor.

It can run on batteries if you use a solid state relay to turn the exposure light on and off thereby adding a minimum of parts to make a fully functional darkroom timer. A simple regulator would add only a few extra parts and allow the use of a "wall-wart" for power. All the functions are in firmware, allowing the use of one switch for control. I sketched in the schematic in Eagle format and here's a jpg image, too. This text file has the parts list and some notes to help you build the timer. Here's the firmware. You
