Suppress Jitter With Hysteresis Circuit

Description: When the comparator's output transitions from low to high, the rising edge of the output pulse, differentiated by the Cl/Rl chain, activates Ql. This action blocks the comparator via its strobing input and maintains its output state for a duration defined by the time constant RlCv. After CI is charged by the current flowing through R1, Ql is turned off, and the comparator is released. When the comparator's output changes from high to low, a similar process occurs, involving elements R2, C2, and Q2. In many applications, the output transition in only one direction is crucial, allowing for the omission of elements that provide temporal hysteresis for the opposite direction transition.

In this circuit design, a comparator is employed to monitor a specific voltage level and output a signal based on that level. The key components include resistors, capacitors, and transistors that work together to create a stable output with controlled timing characteristics.

The operation begins when the comparator detects a voltage level below a predefined threshold, resulting in a low output state. Upon the voltage rising above this threshold, the output transitions to high. This transition is coupled with a differentiation process through the capacitor Cl and resistor Rl, generating a sharp rising edge. This edge is critical as it triggers transistor Ql to turn on, effectively blocking the comparator's feedback through its strobing input. This action maintains the output in a high state for a period determined by the time constant formed by Rl and Cv, ensuring that the comparator does not react immediately to noise or fluctuations in the input signal.

Once the capacitor CI is charged by the current flowing through resistor R1, the voltage across CI reaches a level that turns off transistor Ql, thereby releasing the comparator to respond to further changes in the input signal. The process is mirrored when the output transitions from high to low, with the additional components R2, C2, and transistor Q2 managing the timing for this transition.

In applications where only one directional output transition is necessary, the circuit can be simplified by omitting the elements that provide temporal hysteresis for the opposite transition. This design choice enhances circuit efficiency and reduces component count, making it suitable for specific applications where rapid response to a single transition is critical. The overall design ensures reliable operation in various electronic systems, maintaining stability and responsiveness to input changes. When the comparator`s output changes its state from low to high, the rising edge of the output pulse, differentiated by the Cl/Rl chain, opens Ql. This blocks comparator via its strobing input and sustains its output in the state for a period of time, defined by the time constant RlCv After CI is charged by the current flowing through R1, Ql is shut off and the comparator is released.

When the comparator`s output state changes from high to low, a similar process, involving elements R2, C2, and Q2, occurs. In many applications, the output transition in only one direction is of vital importance, and the elements, which provide temporal hysteresis for the opposite direction transition, can be omitted.
