Sine wave output V F converter
Most of the voltage-to-frequency (V/F) converters discussed in this chapter generate pulse or square-wave outputs. However, many applications, such as audio processing, filtering, or automatic equipment testing, necessitate a sine-wave output, which is produced by this particular circuit. The sine...
Crystal Oscillator Circuit
A crystal oscillator circuit is a straightforward oscillator circuit that can be easily understood through its schematic diagram. It serves as a replacement for a conventional oscillator network, which typically consists of an LC combination. This simplicity is also evident...
Pure Sine Wave Generator
This circuit generates sine waves ranging from 1 kHz to 25 kHz with a total harmonic distortion (THD) of better than -80 dB. It comprises a 4th-order low-pass filter and a TTL counter.
The circuit utilizes a sine wave oscillator to...
Sine wave oscillator
The Wien bridge sine wave oscillator is an oscillator that operates by utilizing positive feedback to return the oscillation output to the input. The key aspect of this circuit is the negative feedback mechanism, which ensures stable oscillation operation. In...
SM5021 Crystal Oscillator Module IC
The CF8223A is an FSK (Frequency Shift Keying) decoder and DTMF (Dual Tone Multi-Frequency) receiver integrated circuit (IC). It is manufactured using a CMOS process and includes a power-down feature for low power dissipation operation. The FSK decoder and DTMF...
Wide-range-oscillator
The gain control enables the oscillator to maintain a nearly constant output across its range. The circuit operates within a frequency range of 160 kHz to 12 MHz while producing a consistent amplitude.
The oscillator circuit described utilizes a gain control...
Oscillator DesignGuide Reference
The Oscillator Design Guide is integrated into Agilent EEsof's Advanced Design System environment, functioning as a smart library and interactive handbook for the creation of effective designs. It facilitates quick oscillator design, interactive component characterization, and provides in-depth insights into...
Electronic Gong Circuit
The electronic gong consists of an oscillator utilizing half of a 74C00 quad 2-input NAND gate, an active twin-T filter based on a TL081 operational amplifier, and an audio amplifier integrated circuit, such as the LM386N. Pulses generated by an...
Sine Wave Generator (1KHz Frequency)
This is a kHz sine wave generator circuit built based on the configuration of an inverted Wien bridge (see C1-R3 C2-R4). R5 and R7 are used for output amplitude setting. Set R5 to read 1V RMS on an audio millivoltmeter...
